Arranging, feeding, and packaging bottles in a whole package  manner is particularly fast and efficient;

model：PDB-S1000

Working system: PLC+touch screen+servo+frequency converter

Packaging speed：8000-15000bottles per hour （There are  differences depending on the product）

Applicable bottle range：50ML-1L（Some bottles require  customized racks）

Packaging width range：450-700MM

Packaging length range： 500-1200MM

Conveying type: chain plate conveying

Conveying speed：8-25M/min

packing material：PO\PE thickness 0.03-0.04MM；

Applicable film requirements: The inner paper core is 78MM standard,  and the outer diameter of the film is ≤ 350MM

Bagging method: automatic

Sealing method: hot bonding

Air source：0.4-0.6Mpa

Power supply: 3-phase AC380V/50Hz

Power consumption：7.0kw
